Background and potential as a bioweapon
Smallpox is caused by the variola virus (VARV), a member of the Orthopoxvirus (OPV) genus of the Poxviridae. In the past, the disease was named smallpox because the lesion size was smaller than great-pox (syphilis) (Meyer et al. 2020).
Widespread vaccination programs were responsible for the global eradication of smallpox, which was certified by the World Health Organization (WHO) on May 8, 1980. The last person to die from smallpox was Janet Parker, a medical photographer at England’s Birmingham University Medical School. Janet Parker died on September 11, 1978 (CDC. History of Smallpox. n.d.).
Although smallpox has been eliminated from its human reservoir, viable variola virus (VARV) is kept in two maximum security laboratories, one in Russia and the other in the U.S. Unfortunately, the 2001 intentional release of anthrax genetically similar to samples held under the control of the U.S. Department of Defense (DoD) has demonstrated that even the highest biohazard security is fallible.
Beside a possible breach of the repositories in Russia and the U.S., other possible threats by malicious actors have been recognized:
Historical Example of Smallpox Weaponization The weaponization of smallpox in the American colonies during the 1700s is recorded in communications from Sir Jeffrey Amherst, the British Commander-in-Chief of the Forces in North America during the French and Indian Wars. Sir Jeffrey Amherst wrote "Could it not be contrived to Send the Small Pox among those Disaffected Tribes of Indians? We must, on this occasion, Use Every Stratagem in our power to Reduce them.” and "as well as try Every other method that can serve to Extirpate this Execreble [sic] Race.” |
The threat to the U.S. is far greater today because routine vaccination ended in the U.S. more than 25 years ago; as a result, the vast majority of our highly mobile population is without any immunity and is highly susceptible. Today's transportation systems could spread smallpox quickly throughout the world. The CDC states "Even a single confirmed case of smallpox today would be considered an emergency" (CDC. The Threat. n.d.).
Instant Feedback:
Recombinant Variola virus could be engineered and produced by malicious actors .
|
| The last known person in the world to have smallpox of any kind. Here 23-year-old Ali Maow Maalin of Merka, Somalia exhibits the pox of Variola minor. |
Transmission
Prior to the eradication of smallpox most cases were spread person to person by respiratory droplet transfer during face-to-face exposure. Smallpox virus could also be transmitted during direct contact with infectious body fluid or contaminated objects like bedding. In the 1978 case of Janet Parker, the last smallpox fatality, the source of the infection was almost certainly the smallpox laboratory at Birmingham Medical School, UK - where Mrs. Parker worked. Unfortunately it was never satisfactorily determined whether the virus was transmitted by air currents through ventilation ducts, by personal contact or contact with contaminated objects.
A modern weaponized airborne form of smallpox could be transmitted to a vast numbers of people before the etiology and scale of the contagion would be identified. The death rate from an aerosolized smallpox weapon would likely be higher than in previous naturally occurring epidemics because the majority of the population lacks immunity. Weaponization could yield a virus with a shorter incubation time, increased stability, virulence, vaccine resistance, and a different symptom profile.
Instant Feedback:
Due to the fact that most of the world’s population has no immunity to smallpox, the human cost of smallpox terrorism could be higher than any previous epidemics.
Historically, the seasonal occurrence of smallpox is similar to that of chickenpox and measles – with incidence higher in winter and spring. The infectious dose is unknown, but is believed to be only a few virion. In the 1960’s and 1970’s in Europe, during a very limited smallpox outbreak, individuals with the infection transmitted smallpox to as many as 10 to 20 other people.
The virus that causes smallpox occurs in two predominant strains – variola major(right), which has a 30% or greater mortality rate, and variola minor, with a 1% mortality rate. Hemorrhagic smallpox and malignant smallpox are two rare but deadly strains of the disease. Before the introduction of smallpox vaccination, almost everyone eventually developed smallpox, and either died of it or developed immunity.
Instant Feedback:
Before the introduction of smallpox vaccination, nearly everyone developed smallpox and died from it or developed lifelong immunity.
MAJOR SMALLPOX CRITERIA FEBRILE PRODROME: occurring 1-4 days before rash onset: fever ≥101°F and at least one of the following: prostration, headache, backache, chills, vomiting or severe abdominal pain |
MINOR SMALLPOX CRITERIA Centrifugal distribution: greatest concentration of lesions on face and distal extremities |
Clinical Course
Smallpox, as a disease, was relatively easy to recognize with its characteristic skin lesions, however, the following exanthematous diseases should be considered as differential diagnoses: severe chickenpox rash, monkeypox, generalized vaccinia virus or cowpox virus infections an several others. (Meyer et al. , 2020).
The incubation period of smallpox ranges from 7 to 17 days, with an average length of time between exposure and symptom development of 12 to 14 days. The patient then typically develops a high fever, malaise, and prostration, with headache and backache. Severe abdominal pain and delirium are sometimes present. A maculopapular rash then appears on the mucosa of the mouth and throat, and the face and forearms, and spreads to the trunk and legs. A person with smallpox is sometimes contagious with onset of fever (prodrome phase), but the person becomes most contagious with the onset of rash. The lesions that first appear in the mouth and throat release large amounts of virus into the saliva. Smallpox pustules are characteristically round, hard, and deeply embedded in the dermis. Crusts begin to form on about the eighth or ninth day of the rash. As the patient recovers, the scabs separate and pitted scars develop, primarily on the face.
Instant Feedback:
Patients with smallpox can transmit the disease before the rash appears
Ordinary smallpox was the most common form, accounting for over 85% of all cases during the smallpox era. |
Modified-type smallpox occurs in previously vaccinated individuals. May also be fewer, more superficial lesions than those seen in ordinary smallpox. Patients also do not tend to have a fever during the evolution of the rash. |
Very rare, and is characterized by intense toxemia, majority of flat-type smallpox cases are fatal. If the patient survives, the lesions gradually disappear without forming scabs |
More common in adults and pregnant women. Death usually occurs by the 5th or 6th day of the rash, often before characteristic smallpox lesions develop. Death results from a profound toxemia, leading to multi-organ failure. |
Treatment
Treatment of smallpox patients generally involves supportive care.
Controlling an epidemic – detection, isolation, surveillance, and vaccination strategies
As soon as the diagnosis of smallpox is made, all persons who are suspected of being infected with smallpox should be immediately isolated and all contacts should be vaccinated and placed under surveillance. It is recommended that contacts be defined as persons who have been in the same household as the infected individual or who have been in face to face contact with the patient after the onset of fever.
Because the widespread dissemination of smallpox virus by aerosol poses a serious threat in hospitals, patients should be isolated at home or in other non-hospital facilities whenever possible. During the worldwide eradication campaign, investigations showed that smallpox was spread throughout hospitals via ventilation systems. Hospital acquired infections may be acquired as a result of droplets spread from patients to staff and visitors in reasonably close contact or by a fine particle aerosol.
In one situation in Germany, a smallpox patient with a cough, who was isolated in a single room, infected persons on 3 separate floors of the hospital. A number of outbreaks have also occurred in laundry workers who handled linens and blankets used by patients. It is recommended in an outbreak setting that all hospital employees as well as patients in the hospital be vaccinated. For persons who are immunocompromised or for whom vaccine is otherwise contraindicated, vaccine immune globulin (VIG) can be given as an alternative.
Instant Feedback:
Due to the ease of transmission of smallpox in hospitals, most patients with smallpox should be cared for at home if possible.
If a large outbreak occurs, patients who have active smallpox infections may be quarantined. Although cooperation by most patients and contacts in observing isolation could be ensured through counseling and persuasion, there may be some for whom forcible quarantine will be required. Some states and cities in the U.S., but not all, confer broad discretionary powers on health authorities to ensure the safety of the public’s health and at one time this included powers to quarantine. Under epidemic circumstances, this could be an important power to have. In larger outbreaks, home isolations and care should be the objective for most patients.
Care
Only personnel who have been vaccinated against smallpox OR vaccinate personnel within 72 hours of their first exposure to the patient (preferably within 24 hours). Personnel should wear personal protective equipment (PPE) and adhere to standard, contact, and airborne precautions. practice strict infection control measures in caring for a patient with smallpox in the home. All contaminated instruments, surfaces, excretions, fluids, and other materials should be incinerated or decontaminated chemically. Clothing and bedding should be incinerated, autoclaved, or washed as directed by public health authorities in hot water and hypochlorite bleach.
Instant Feedback:
A single smallpox vaccination produces lifelong immunity to the disease.
There are some risks associated with smallpox vaccination. Complications of smallpox vaccination include postvaccinal encephalitis, progressive vaccinia – a condition in which the vaccination lesion fails to heal. Additionally, can involve other body tissues, and accidental inoculation of other body parts such as the eyes or mouth, usually by scratching the smallpox vaccination site.
People considered to be at particular risk of smallpox vaccine complications include:
Vaccinia immune globulin intravenous (VIGIV) may be given as an alternative to patients in high-risk groups. VIGIV may also be given to treat patients with progressive vaccinia. The U.S. government has contracted with Emergent Biosolutions to produce VIGIV in the ratio of 1:10,000 doses of smallpox (vaccinia) vaccine stored in the U.S. SNS.
CONTRAINDICATIONS
VIGIV is contraindicated in isolated vaccinia keratitis. • VIGIV is contraindicated in individuals with a history of anaphylaxis or prior severe systemic reaction associated with the parenteral administration of this or other human immune globulin preparations. • VIGIV is contraindicated in IgA-deficient patients with antibodies against IgA and a history of IgA hypersensitivity, as it contains trace amounts of IgA (40 mcg/mL) (FDA. VIGIV label. 2005).
Post-exposure vaccination
Vaccination given within the first few days after exposure to a person with smallpox may prevent or lessen smallpox symptoms. Should a smallpox outbreak occur, an emergency vaccination program would be implemented. The vaccine program would include all health care workers at clinics or hospitals that might receive patients, all other essential disaster response personnel, such as police, firefighters, public health and emergency personnel and mortuary staff who might have to handle bodies. Both airborne and contact precautions should also be used in postmortem care. Whenever possible, patients who die of smallpox should be cremated.
